Audison Forza AF C8.14 bit – 8 Channel DSP Amplifier

Audison Forza AF C8.14 bit - 8 Channel DSP Amplifier

Description

Read More

£799.99
Item added to wishlist View Wishlist
Item removed from wishlist

The Audison Forza AF C8.14 bit is a premium 8-channel Class D amplifier with an integrated 14-channel DSP, designed to deliver exceptional sound quality and complete control over your vehicle’s audio system. Combining powerful amplification with advanced digital signal processing, it is the perfect solution for upgrading factory audio systems or building high-performance custom installations.

With 65W RMS x 8 at 4Ω (100W RMS x 8 at 2Ω) and fully bridgeable outputs delivering up to 200W x 4, the AF C8.14 bit provides outstanding flexibility for powering active speaker systems, multiple amplifiers, or larger audio upgrades. Its compact design allows for easy installation, while the built-in 24-bit/96kHz DSP offers precise tuning capabilities to create a perfectly balanced listening experience.

Perfect for enthusiasts and professional installers looking for a powerful all-in-one DSP amplifier that delivers premium Audison sound quality, advanced tuning capabilities and seamless OEM integration.

Specifications:

  • Power Supply
    Specification Value
    Operating Voltage 11 – 15 VDC
    Pulse Operating Voltage 6.5 – 17.5 VDC
    Fuse Rating 2 × 30A
    Idle Current 1.5A
    Standby Current 1.7mA
    Current Draw (Max Musical Power @ 14.4V) 55A
    Remote Input 4 – 15 VDC (1mA)
    Remote Output 6.5 – 15 VDC (150mA)
    Automatic Remote Turn-On (ART) 1.5 VDC
    Efficiency 82% @ Rated Power (4Ω, 1% THD)
    Amplifier Performance
    Specification Value
    Channels 8
    RMS Power @ 4Ω 65W × 8
    RMS Power @ 2Ω 100W × 8
    Bridged Power @ 4Ω 200W × 4
    Minimum Load Impedance 2Ω Stereo / 4Ω Bridged
    Frequency Response 10Hz – 42kHz
    THD+N 0.05%
    Damping Factor 100
    Signal-to-Noise Ratio (Analogue Input) 98.5 dBA
    Signal-to-Noise Ratio (Optical Input) 105 dBA
    CEA Ratings
    Specification Value
    Power Output @ 4Ω 65W × 8
    Signal-to-Noise Ratio 80dB
    Inputs & Outputs
    Analogue Inputs
    • 8 × RCA Pre Inputs (0.6 – 6V RMS)
    • 8 × High-Level Speaker Inputs (expandable to 12 channels with optional F4IN card)
    Digital Inputs
    • Optical S/PDIF (up to 192kHz / 24-bit)
    • Optional Optical/Coaxial S/PDIF via F2O expansion card
    Outputs
    • 6 × DSP Pre-Out (5V RMS)
